Metal end caps for electronic products

Metal end caps for electronic products. product φ 110mm, material thickness is 1.2mm. Through the advantages of the mold,which stretched and formed through two stretching processes.

The roundness tolerance of the product can be controlled within 0.05mm.

Processing steps：

1、directly in the mold by means of the power of conventional or special stamping equipment to obtain shape,size

and performance.

2、deep drawn                                      4、punching and triumming

5、cleaning and polishing

Production Process：

processing：

precision stamping and

deep drawing

Material：

t=1.2mm 304stainless steel
